USED 2011 MIKRON MILL UCP 600 VARIO

5-AXIS MACHINING CENTERS
UCP 600 Vario
SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS
FOLLOWING, WE OFFER FOR YOUR CONSIDERATION:
Used 2011 +GF+ MIKRON UCP600 Vario 5-Axis Machining Center w/7 APC:
*May be inspected in plant under power by appointment*
Machine was made at +GF+ in Nidau, Switzerland 5/2011
CONTROL
Heidenhain iTNC 530 with Ethernet and electronic handwheel for part setup
WORKING RANGE
Longitudinal X-Axis..................................... 23.6" (600 mm)
Cross Y-Axis............................................ 17.7" (450 mm)
Vertical Z-Axis......................................... 17.7" (450 mm)
B-Axis (Swivel)....................................... -115/+30 degrees
C-Axis (Rotary)........................................ n x 360 degrees
FEED DRIVE
Feed Rate X/Y/Z..................................... 590 IPM (15 m/min)
Rapid Speed X/Y/Z................................... 866 IPM (22 m/min)
Rapid Speed B-Axis (Swivel).....................................
