USED 2010 MIKRON MILL HSM600U 36K RPM
Overview
5-AXIS MACHINING CENTERS
HSM600U 36k RPM
SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS
FOLLOWING, WE OFFER FOR YOUR CONSIDERATION:
One used 2010 +GF+ MIKRON HSM600U 5-Axis Machining Center with Plt/Changer:
Machine was made at +GF+ in Nidau, Switzerland
CONTROL
Heidenhain iTNC 530 with Ethernet and electronic handwheel for part setup
WORKING RANGE
FEED DRIVE
DIRECT DRIVE WORK TABLE
Maximum workpiece weight (automatic with pallet changer) 264 lbs (120 kg)
Maximum workpiece diameter that can be pallet changed 16.125" (409.6 mm)
Pallet type this machine is equipped with.. EROWA UPC Workpiece Pallets
With hydraulic clamping in turning and swivelling axis
All feed motors are liquid-cooled
Direct measuring system HEIDENHAIN rotary encoders B/C axes
AUTOMATION
WEIGHT
SPINDLE
EQUIPPED WITH:
Flood coolant on outside of spindle
Scraper chip conveyor
Direct measuring system HEIDENHAIN glass scales X/Y/Z axes
Direct measuring system HEIDENHAIN rotary encoders B/C axes
Fully enclosed machine enclosure
SMM (Smart Machine Modules):
Advanced Process System-APS
Intelligent Thermal Control-ITC
Intelligent Thermal Control 5-axis-ITC 5-axis
Operator Support System-OSS
Beacon/Signal Lamp
Tool blow-off unit
Oil mist spray unit
Specs
Status: Available
Number of axis: 5-Axis
Tool changer: 60 ATC
Control: HH iTNC 530
Spindle: 36,000 rpm
Spindle taper: HSK-E50
X axis: 31.5" (800 mm)
Y axis: 23.6" (600 mm)
B axis: +30/-110 degrees
Z axis: 19.7" (500 mm)
C axis: 360 x 0.001 degrees
Longitudinal x-axis: 31.5" (800 mm)
Cross y-axis: 23.6" (600 mm)
Vertical z-axis: 19.7" (500 mm)
B-axis (swivel): +30/-110 degrees
C-axis (rotary): n x 360 degrees
Number of simultaneous axis: 5/5 simultaneous
Feed rate x/y/z: 1,653 IPM (42 m/min)
Feed rate b-axis (swivel): 200 RPM
Feed rate c-axis (rotary): 360 RPM
Acceleration x/y/z: up to 17 m/sec2
Clamping surface: 12.6" x 12.6" (320 mm x 320 mm)
Maximum workpiece weight (manual loading): 661 lbs (300 kg)
Maximum workpiece diameter that can be machined: 15" (381 mm)
Number of pallets this machine is equipped with: 7 pallet stations
Tool magazine automatic tool changer: 60 positions
Laser tool measuring system: Standard
Infrared parts measuring touch probe: M&H
Upc automatic pallet changer number of pallets: 7 pallet stations
Including pallet changer: Approximately 20,282 lbs (9,200 kg)
Machine base: Polymer concrete (man made granite)
Spindle rpm: 36,000 RPM
Spindle power 40% ed: 33.5 HP (25 kW)
Spindle torque 40% ed: 14.75 Ft/Lb (20 Nm)
