USED 2013 MIKRON MILL HSM 600U LP
Overview
5-AXIS MACHINING CENTERS
MIKRON HSM 600U LP
One used 2013 +GF+ MIKRON HSM 600U LP 5-Axis Machining Center with Pallet Changer:
SWISS MADE
Machine was manufactured at +GF+ in Nidau, Switzerland
CONTROL
HEIDENHAIN iTNC 530 with Ethernet and electronic handwheel for part setup
Control software options:
"APS" Option-Advanced Process System
Extended "APS" Option
"ITC" Option-Intelligent Thermal Control
"ITC-5X" Option-Intelligent Thermal Control for 5 axis
"OSS" Option-Operator Support System
Diagnostic option MT connect
WORKAREA
Longitudinal X-Axis..................................... 31.5" (800 mm)
Lateral Y-Axis.......................................... 23.6" (600 mm)
Vertical Z-Axis......................................... 19.7" (500 mm)
B-Axis (Swivelling axis).............................. +30/-110 degrees
C-Axis (Rotary axis)................................... n x 360 degrees
Number of simultaneous axis........................... 5/5 simultaneous
Specs
Number of axis: 5-Axis
Tool changer: 220 ATC Tool Tower
Control: HH iTNC 530
Spindle: 36,000 rpm
Spindle taper: HSK-E50
X axis: 31.5" (800 mm)
Y axis: 23.6" (600 mm)
B axis: +30/-110 degrees
Z axis: 19.7" (500 mm)
C axis: 360 x 0.001 degrees
