USED 2011 MIKRON MILL HSM 600U
Overview
5-AXIS MACHINING CENTERS
HSM 600U
SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION:
One used 2011 MIKRON HSM600U 5-AXIS Machining Center with 7 X Pallet Chngr:
Machine was manufactured in Nidau, Switzerland
CONTROL
Heidenhain iTNC 530 with Ethernet and electronic handwheel for part setup
WORKING RANGE
Longitudinal X-Axis..................................... 31.5" (800 mm)
Cross Y-Axis............................................ 23.6" (600 mm)
Vertical Z-Axis......................................... 19.7" (500 mm)
B-Axis (Swivel)....................................... +30/-110 degrees
C-Axis (Rotary)........................................ n x 360 degrees
Number of simultaneous axis........................... 5/5 simultaneous
FEED DRIVE
Feed Rate X/Y/Z................................... 1,653 IPM (42 m/min)
Feed Rate B-Axis (Swivel)...................................... 200 RPM
Feed Rate C-Axis (Rotary).........................
Specs
B axis: +30/-110 degrees
C axis: 360 x 0.001 degrees
X axis: 31.5" (800 mm)
Y axis: 23.6" (600 mm)
Z axis: 19.7" (500 mm)
Control: HH iTNC 530
Spindle: 24,000 rpm
Tool changer: 50 ATC
Spindle taper: HSK-A 63
Number of axis: Full 5-Axis
