USED ELO E231195 ET1093L

The Elo ET1093L (P/N E231195) is a 10.1-inch open-frame LCD touchscreen from Elo's 90-Series product line, designed for OEM integration into kiosks, retail self-service, casino/amusement, and industrial automation environments. It features a slim, zero-bezel design powered by an energy-saving LED backlight and Elo's TouchPro™ Projected Capacitive (PCAP) multi-touch technology supporting up to 10 simultaneous touch points. The display offers stable, drift-free operation with 1280x800 WXGA resolution, 800:1 contrast ratio, 350 cd/m² brightness, IP65-rated front bezel (when sealed), and universal 100–240V AC input for worldwide deployment.
Specification
Value
Brand
Elo
Model / Part Number
E231195 ET1093L
Product Series
90-Series Open Frame
Screen Size
10.1 inches (25.6 cm diagonal)
Display Technology
TFT-LCD with LED Backlight
Native Resolution
1280 x 800 (WXGA)
Aspect Ratio
16:10
Colors Supported
262,144 (18-bit)
Brightness (Typical)
350 cd/m² (nits)
Contrast Ratio
800:1
Response Time
25 ms
Viewing Angle (H/V)
170° / 170°
Active Display Area (H x V)
216.96 x 135.6 mm
Touch Technology
TouchPro™ Projected Capacitive (PCAP)
Touch Points
10-touch (multi-touch)
Touch Interface
USB 2.0
Surface Treatment
Clear (zero-bezel)
Video Interfaces
HDMI, VGA, DisplayPort
Supported Resolutions
640x480, 720x400, 800x600, 1024x768, 1280x800, 1920x1080
AC Input Voltage
100–240 V AC
AC Input Frequency
50–60 Hz
DC Input (Internal)
12V DC
Power Consumption (Typical)
6.1 W
Power Consumption (PowerSave)
0.7 W
Power Consumption (Off)
0.5 W
VESA Mounting Pattern
75 x 75 mm (M4 screws), VESA MIS-E,C
Mounting Type
Open Frame / Flush Mount
IP Rating (Front)
IP65 (PCAP units, when sealed)
MTBF
50,000 hours demonstrated
OSD Control
Tethered OSD Control Box
Color
Black
Agency Approvals
UL, FCC, cUL, IC, CCC, CE, TUV, VCCI, KCC, CoC, BSMI, CB, EAC, RoHS, China RoHS, WEEE
What's in the Box
HDMI Cable, VGA Cable, OSD Remote, Touch USB Cable, Quick Install Guide, Flush Mount Brackets w/Screws
We warranty all items for 30 days from date of purchase.
