USED ICOP PMX-090T

The ICOP PMX-090T is an ultra-compact industrial Touch Panel PC built around the DM&P Vortex86MX+ SoC processor running at up to 1GHz, featuring a 9-inch WSVGA TFT LCD with resistive touchscreen. It is designed for demanding embedded and industrial HMI applications, providing an IP65-rated front panel for splash and dust resistance, an integrated 10/100M Ethernet port for network connectivity, and support for Linux, Windows CE, and Windows XP environments. The fanless, wide-range 8–35VDC input design makes it suitable for harsh industrial environments. The unit is discontinued by the manufacturer but remains widely available through industrial surplus channels.
Specification
Value
Brand
ICOP
Model / Part Number
PMX-090T
Product Type
Touch Panel PC / HMI
CPU
DM&P Vortex86MX+ SoC, up to 1GHz
CPU Cache (L1)
16KB I-Cache + 16KB D-Cache
CPU Cache (L2)
256KB
BIOS
AMI BIOS
Memory
512MB or 1GB DDR2 (onboard, variant-dependent)
Display Size
9 inches TFT LCD (WSVGA)
Display Resolution
1024 x 600 pixels
Contrast Ratio
500:1
Viewing Angle (Vertical)
120 degrees
Viewing Angle (Horizontal)
140 degrees
Touchscreen Type
Resistive
Input Voltage
+8V to +35V DC (variant-dependent; 5A or 8A power connector)
Rated Voltage (Radwell)
24 VDC
Rated Current
2A
Ethernet
Integrated 10/100 Mbps (RJ45)
Serial Port
1x COM (RS-232 / RS-422 / RS-485, BIOS selectable)
USB Ports
2x USB
Audio
HD Audio — Realtek ALC262 CODEC, 1x Line-Out
Storage Slots
1x Compact Flash Slot, 1x MicroSD Slot
Keyboard Port
1x PS/2 Keyboard
Watchdog Timer
Software programmable, 30.5μs to 512 seconds x 2 sets
Graphics
Integrated RDC Display chip (~1–1.5W power consumption)
Supported OS
Linux, Windows CE, Windows XP
Dimensions
236.6 x 146 x 35 mm (9.31 x 5.75 x 1.38 in)
Weight
468g / ~2.01 lbs
Wireless
Optional (antenna port available on select variants)
Status
Discontinued by Manufacturer
We warranty all items for 30 days from date of purchase.
