USED 2003 HERMLE C800U

5-AXIS MACHINING CENTERS
C800U
SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS
FOLLOWING, WE OFFER FOR YOUR CONSIDERATION:
One used 2003 HERMLE C800U full 5-Axis VMC:
May be inspected under power by appointment in our Wisconsin showroom
Machine was made at Maschinenfabrik Berthold Hermle AG in Gosheim, Germany
HEIDENHAIN TNC 530 CNC Control with hand held electric control unit
WORKING RANGE
X-Axis.................................................. 31.5" (800 mm)
Y-Axis................................................. 23.62" (600 mm)
Z-Axis.................................................. 19.7" (500 mm)
FEED DRIVES
Feed force...................................................... 8000 N
Rapid movement.................................... 1,378 IPM (35 m/min)
Acceleration.................................................... 5 m/s2
Diameter and pitch of the ball screws X & Z axis 40/20 mm; Y axis 50/20mm
DIRECT MEASURING SYSTEM
Resolution.....................................
