NEW GOODWAY GLS-3300YM
Overview
With the latest machine tools technology and precision turning performance, GOODWAY brings you the new GLS series high-speed CNC turning center. Using 2 types of beds combined with super rigidity, high-speed turning capability, and compact size provides you with super-efficiency cutting power. The GLS series equipped with an optional live tooling turret, Y-axis, and sub-spindle can work on turning, milling, and drilling tasks at the same time to increase the output capacity with high-end value to meet your needs of today and tomorrow.
Key Features:
• 30˚ slant-bed design provides smooth chip disposal and easier operator access.
• Steel way covers and special steel wipers molded with industrial-strength rubber are used for durability.
• Fully enclosed splash guards keep chips and coolant contained for a safe clean working environment.
The auto lubrication system delivers metered amounts of lubrication to the slideways, ball screws, and vital components. Distribution is automatically shut off during idling to prevent waste.
Specs
Equipped With
UPGRADED FANUC OI-F 15" LCD INCL. HMI & MANUAL GUIDE I
12" TAIWAN MADE 3 JAWS CHUCK WITH ONE SET EA. SOFT & HARD JAWS
BAR CAPACITY 90MM
GOODWAY 12 STATION LIVE TOOLING TURRET, DRIVEN TOOL MOTOR 7KW), ID SHANK 40MM, OD SHANK 25MM, LIVE TOOL COLLET ER-32(1-20MM), MAX. SPEED 6000RPM
C AXIS WITH DISK BRAKE ON MAIN SPINDLE (MAX. SPEED 33RPM, TORQUE 240 N-M)
FANUC P TYPE SPINDLE MOTOR 15/18.5KW
HIGH PRECISION LINEAR WAYS
2X 0 DEGREE HOLDERS
2X 90 DEGREE HOLDERS
Y-AXIS (MAX. TURNING DIA. 400MM, MAX. X AXIS TRAVEL 270MM, +/-50MM, FEEDRATE MOTOR 2.7KW, Y AXES 12M/MIN, LINEAR WAY, X/Y AXES THRUST (CONT.) 961/961 KGF
FANUC ABSOLUTE ENCODER AC SERVO DRIVE MOTORS
C3 CLASS BALL SCREWS WITH PRETENSION ON ALL AXES
CHIP CONVEYOR (HINGE TYPE) WITH AUTO TIMER
AIR BLOW FOR MAIN SPINDLE CHUCK (OR SUB-SPINDLE CHUCK)
COOLANT ABOVE MAIN SPINDLE CHUCK (OR SUB-SPINDLE CHUCK)
COOLANT GUN WITH PIPE CONTROL
OIL MIST COLLECTOR
OIL SKIMMER
HYDRAULIC TYPE LP-1 PROGRAMMABLETAIL STOCK BUILT IN TYPE DEAD CENTER MT3) QUILL DIA. 70MM, QUILL TRAVEL 150MM, TAIL STOCK BODY TRAVEL 600MM
DEAD CENTER FOR TAIL STOCK MT3
AUTO RENISHAW TOOL SETTER HPMA FOR MAIN SPINDLE
COOLANT SYSTEM WITH GRUNDFOS 3/4 HP COOLANT PUMP RATED AT 55PSI (3 BARS)
HYDRAULIC SYSTEM
FULLY ENCLOSED SPLASH COVERS
ADVANCE AUTO LUBRICATION SYSTEM
TRI-COLOR SIGNAL TOWER(YELLOW/RED/GREEN)
HIGH INTESITY WORK LIGHT
M CODE AUTOMATIC POWER OFF
FOOT SWITCH FOR CHUCK
RS-232 INTERFACE
ELECTRIC CABINET HEAT EXCHANGER
FOUNDATION AND LEVELING KIT/MAINTENANCE TOOL KIT
OPERTION & MAINTENANCE MANUALS
