Used INYMASSA approximately 10,700 litre total capacity 316/316L stainless steel vertical reactor. Unit has welded Klopper dished top and bottom heads with shell height of approximately 4,210mm. Internal rated atmospheric pressure design at 100 °C. Fitted with external half-coil jacket (material to be confirmed) of approximately 400 litre volume, rated 6 bar design pressure at 100 °C. Includes top-mounted impeller agitator. Mounted on support brackets.
| Capacity | 2,831.7 gal | 10,719.1 L |
| Type of stainless | 316/316L | 316/316L |
| Internal Pressure | 0 PSI | 0 bar |
| Internal Temperature | 212°F | 100°C |
| Jacket Pressure | 87 PSI | 6 bar |
| Straight Side | 165.7" | 4,208.8 mm |
| Type Of Heads | Klopper | Klopper |
