NEW STANZA SB

Stanza Model SB 1350/3 52" - 3 Abrasive Stations
Number of Heads: 3
Conveyor Width: 52"
Max. Workpiece Thickness: 3"
Sanding Motors (3): 3 Hp each
Motor Drive System: belt driven with inverter controls
Feed Motor: 1 Hp
Head Rotation Speed: 100 to 700 RPM, individual controls with reversing switch
Hold Down System: adjustable spring-loaded rolls, vacuum table optional
Thickness Setting: fixed table with adjustable heads
Head Adjustment: individual rise and fall with digital counters
Head Change: quick-change carriage units
Head Configuration Choices: planetary, cross-belt, drum
Electrical Requirements: 460v 3ph 60Hz, 220v is optional
Options (built to order)
Planetary w/ choice of abrasive
Cross Belt
12" Diameter Drum Unit w/ choice of abrasive
