NEW SOCOMEC 22143503

The Socomec 22143503 is a SIRCO M Series enclosed rotary non-fusible disconnect switch designed for safe control and disconnection of motor and load circuits in industrial applications. It features a 3-pole, 30-amp, 600V AC/DC rating with a 65kA short-circuit current rating (SCCR) and is housed in a polycarbonate enclosure with a red ergonomic padlockable handle. The unit is UL 508 listed for use as a motor-rated or local disconnect and meets NEMA ratings 1, 3R, 12, 4, and 4X, making it suitable for a wide range of indoor and outdoor environments.
Specification
Value
Brand
Socomec
Model / Part Number
22143503
Series
SIRCO M
Switch Sub-Model
SIRCO M1
Product Type
Enclosed Rotary Non-Fusible Disconnect Switch (Load Break Switch)
Number of Poles
3
Current Rating
30A
Voltage Rating
600V AC/DC
Short-Circuit Current Rating (SCCR)
65kA
NEMA Enclosure Rating
NEMA 1, 3R, 12, 4, 4X
UL Listing
UL 508 (Motor-Rated Disconnect / Local Disconnect)
CSA Standard
CSA C22.2§14, Class 3211-05, File 112964
IEC Standard
IEC 60947-3
Enclosure Material
Polycarbonate
Handle Color
Red
Enclosure Color
Grey
Mounting Type
Wall Mount
Operation Type
Front Operated, Rotary
Fusible
Non-Fusible
Load Break Capable
Yes
Padlockable Handle
Yes (up to 3 padlocks)
Removable Ground Terminal
1 Included
Auxiliary Contact Option
Yes (1 Power Pole + 1 Auxiliary Contact addable)
Housing Dimensions (W x H x D)
3.9 x 6.38 x 4.37 in
Applications
NEC Motor Disconnect, OSHA Lockout/Tagout, Main Non-Fusible Disconnect, Load Transfer
We warranty all items for 30 days from date of purchase.
