USED MEREEN-JOHNSON 110-C
Overview
Specs
Mereen-Johnson 110-C Equalizer
Equalizer Vertical Hopper feeds One Piece per Lug,
Trim Motors on LH and RH sides.
Single Piece or unsurfaced Glued-up Panels
Two 7-1/2 HP 3600 RPM TEFC Standard Frame Arbor Motors Tilting From 0 to 45 Degrees
Arbor Motors arranged for 3 phase, 60 Hertz, 460V, 24v DC Controls Voltage.
Tooling for Collar 3.5" Die x .19" Tool spacing
Tooling to Face Mount with 6 3/8"-16 N C Bolts spaced on 4.25" bolt circle
Motor Mounted Dust Hoods with 5" Dust Port, 680 CFM, Total 1360 CFM
Precision-toothed Belting with steel cords and 5/8" Bolt-on feed Lugs on 14.33" Centers
Full-Length Spring-loaded Shoe Hold-downs.
Cable-Type Emergency Stop Safety Switches Mounted on top of Hold-Down Beams
1/2 HP TEFC AC GearHead Motor for Transverse of RH adjustable Belt Beam
Vertical Hopper Infeed- 20" Nominal Height Capacity, Side Guides adjustable for maximum 2" trim/overhand each side
Max Width Capacity: 36"
Air Cylinder Mounted on LH Side Guide to align Stock Prior to entering Hold Downs.
