NEW DIEHL SL-35

Diehl Model SL-35 Straight Line Rip Saw
Diehl's Mid-Sized Rip Saw, an economically priced machine with the speed and performance of large saws, with guaranteed glue line accuracy. All this coupled with Diehl's legendary quality and durability.
Arbor Motor: 15Hp (11.2 Kw), 20Hp (15 Kw) optional
Feed Motor: 2Hp (1.5 Kw)
Feed Speed: Variable, 50 to 140 FPM (12 to 42 mpm)
Stock Min. Thickness: 1/8" (3mm)
Stock Max. Thickness w/ 14" (355mm) Blade: 1.5" (38mm)
Stock Max. Thickness w/ 16" (406mm) Blade: 2.55" (64mm)
Stock Min. Length: 12" (305mm)
Saw Blade Arbor Bore: 2" (50.8mm)
Throat Capacity: 19" (482mm)
Arbor Speed: 3450 RPM
Accurate Glue Line Cut (either straight or hollow): up to 5' (1.5 m)
Voltages Available: 208/240/480/575, 3 phase, 60 cycle, 380, 3 phase, 50 cycle w/ 110 control circuit
Spindle Brake: Automatic
Vacuum: (1) 6" (152mm), (1) 3" (76mm) opening, 1250 CFM (35 cmm) required
Worktable Height: Nominal 34" (864 mm)
Upper Anti-Kickback Fingers w/ Cam Controlled Height
Lower Anti-Kickback Fingers in Table
Dimensions: 65" (1651 mm) L x 53" (1346 mm) W x 56" (1423 mm) H
Weight: net 2750 lb. (1250 kg), Crated: 2960 lb. (1345 kg), Crated For Export Shipment: 3275 lb. (1485 kg)
