Elcon Model 155 DS Vertical Panel Saw
Ridged, welded box steel frame with three vertical cutting positions
Round upper guide rail with concave bearings for smooth operation
Equipped with panel transport rollers at base
Segmented midway fence that is the full length of frame
3kw (~4hp) motor
10" blade capacity
Double cut plunge scoring system
Automatic moveable panel support grid
Manual plunge of saw head
Two pneumatic panel clamps
Programmable rail for predetermined horizontal cuts
Repeat rip guide
Both English and metric scales standard
Saw head is counter balanced with chain & safety chain
10" saw blade included
Built-in dust shroud with pipe ready for dust collection
Maximum Cutting Length 129"
Maximum Cutting Height (hor) 59"
Maximum Cutting Height (ver) 61"
Overall length of machine 178"
Overall height of machine 91"
Overall depth of machine 57"
Motor 3kw (4 hp), 3 phase
Blade rpm 5100 rpm
Weight
Frame (1650)
