NEW BAILEIGH DP-1500G-GEAR
Overview
*220V 3-phase 3.5 hp motor.
*Gear-driven drill press.
*1.5″ mild steel drilling capacity.
*Variable speeds: 108 to 1800 rpm.
Features:
3.5 hp motor runs on 220 volt 3-phase power
Drills a maximum capacity of 1.5″ mild steel
Includes an auto tapping feature with a 1.3” capacity
Variable-speed drill press lets you select the correct setting for a project within the continuous range of 108 to 1800 rpm
Standard #4 Morse taper transfers power from the gear head to the material
Cast iron base and mighty 5.5″ diameter steel column eliminate flexing for heavy feeds at max capacity
20″ x 16″ table features large T-slots for a vise or fixture to hold material securely
Includes a chuck, coolant system and a flexible halogen work light as standard features, not upgrades
Protective shield around drill head keeps you and your shop safe
Specs
Weight: 990 lbs
Dimensions: 86 × 23 × 37 in
Base Dimensions: 19.5" x 28"
Drilling Capacity: Inch
Horse Power (HP): 3.50
Input Power: 220V / 3-phase
Motor (HP): 3.5 hp
Shipping Dimensions: 86x23x37
Speed Range: 108-1800
Weight: 1225
