NEW BAILEIGH RDB-350

*220V 3-phase rotary-draw bender
*2.5” schedule 40 pipe capacity
*24” CLR maximum
*Stores 170 bend programs
Features:
Capacity of 2.5” schedule 40 pipe and 3” tube with .187” wall thickness
24” centerline radius maximum and bends to 360° in one shot, both left and right
You can program the desired angle, material springback, and bend speed for easy repeatability
Programmer can also keep track of rotational orientation
Touchscreen controller designed for user-friendly programming
320° rotation of the controller lets you operate RDB-350-TS from any side of the machine
Internal memory can store up to 170 programs of 10 bends per program
Unlimited program storage/backup via the micro-SD port (standard 2CB SD card)
Quick-release counter die system allows you to load and unload the pipe bender quickly for high production runs
Accepts a rotary positioning table, available from in several lengths, to achieve accurate bends on varying planes
