NEW JET JTM-1050
Overview
Features:
12.1″ High resolution display (1024 x 768) with 3D graphics
Available offline software
Built-in calculator: Performs standard, trig, and geometry calculations and transfers them directly into part programs
Closed loop feedback using Acu-Rite precision linear encoders with 0.00005″ resolution
Estimated run time feature
Jog Control allows table movement, quickly from one location to another – using one axis at a time or any two axes simultaneously
Powerful DC Servo motor assemblies that include mounting castings and hardware
Precision ground ball screws eliminate backlash for precise lateral movements
USB + Ethernet compatible
Specs
Weight: 3200 lbs
CNC Package: ACU-RITE MILLPWR® G2
Collet Capacity: 1/8 – 7/8
Max Distance Spindle to Table: 19
Motor (HP): 3 HP, 230/460V, 3Ph
Number of Axis: 3
Quill Diameter: 3-3/8
Quill Down Feed Rates (IPR): .0015 – .003 – .006
Range of Spindle Speeds: 70 – 3,800
Spindle Taper: R-8
Spindle Travel: 5
Style (Type): CNC
Table Cross Travel: 15-1/4
Table Size (L x W): 10 x 50
Travel of Knee: 14-1/4
Travel of Ram: 20-1/2
T-Slot Centers: 2-1/2
Weight: 3200
Work Table Weight Capacity: 720
