NEW HACH LXV404.99.00552
Overview
Unused surplus Hach sc200 Universal Controller, model LXV404.99.00552. Three identical controllers are available and may be purchased individually or as a group.
The sc200 is a two-channel process instrument controller configured to accept two Hach digital sensor inputs. It includes two isolated 4–20 mA analog outputs for transmitting sensor measurements to a plant control, monitoring or SCADA system.
The controller accepts 100–240 VAC, 50/60 Hz electrical power and was specified for operation on a 120 VAC system. It features a high-resolution backlit display, guided sensor calibration, password-protected operation, SD-card support, four programmable SPDT relays and a NEMA 4X/IP66 enclosure suitable for industrial water and wastewater applications.
The sc200 controller is compatible with numerous Hach digital sensors used to monitor dissolved oxygen, pH, ORP, turbidity, suspended solids, nitrate, ammonia, chlorine and other water-quality parameters. Sensors are not included unless specifically shown or stated in the listing.
Approximate controller dimensions are 5.7 inches high by 5.7 inches wide by 7.1 inches deep. Approximate weight is 3.75 pounds.
These controllers were originally furnished for use at a municipal wastewater treatment facility but were placed into warehouse storage.
Equipment is offered as-is. Buyer is responsible for verifying the individual serial number, manufacturing year, condition, included modules, sensor compatibility and suitability for the intended application.
Specs
Manufacturer: Hach
Product series: sc200 Universal Controller
Model/catalog number: LXV404.99.00552
Inventory/SAP stock number: W2T500561
Quantity available: 3
Controller configuration: Two-channel digital
Sensor inputs: Two Hach digital sensor inputs
Analog outputs: Two isolated 4–20 mA outputs
Maximum output load: 550 ohms
Output accuracy: ±0.1% of full scale at 25°C
Input power: 100–240 VAC
Specified system voltage: 120 VAC
Frequency: 50/60 Hz
Display: Backlit transreflective LCD
Display resolution: 240 × 160 pixels
Relays: Four programmable SPDT Form C relays
Relay rating: 5 A, 1,200 W
Enclosure rating: NEMA 4X/IP66
Mounting: Wall, pole or panel mounting
Conduit openings: 1/2-inch NPT
Operating temperature: -4°F to 140°F
Humidity: 0–95% RH, non-condensing
Dimensions: 5.7 H × 5.7 W × 7.1 D inches
Weight: Approximately 3.75 lb
Applications: Municipal wastewater, drinking water, industrial water and process monitoring
Equipped With
Two digital sensor inputs
Two isolated 4–20 mA outputs
Four programmable SPDT relays
Backlit LCD display
Password-protected operating levels
SD-card slot
Visual warning and alarm system
NEMA 4X/IP66 enclosure
Wall, pole or panel mounting capability
