USED 2019 UNIVERSAL 2019 UNIVERSAL UNI 15X22
Overview
General Description:
2019 Universal UNI 15x22 Directional Drill:
-1,292 hours.
Additional Information:
MANUFACTURES EQUIPMENT SPECIFICATIONS:
-Length: 199"
-Width: 65"
-Height: 89
-Weight (With out Rods): 10,600lbs
ENGINE SPECS
-Make and Model: Kubota Turbo Diesel
-Horsepower: 99HP
-# of Cylinders: 4
-Rated RPM: 2500
-Thrust: 23,000lbs
-Pullback: 23,000lbs
-Max Spindle Torque (Low Displacement): 1800 ft/lbs
-Max Spindle Torque (High Displacement):3,600 ft/lbs
-Max Rotation Speed (Low Displacement): 160 RPM
-Max Rotation Speed (High Displacement): 220 RPM
-Max Ground Drive: 3.5MPH
DRILLING FLUID SYSTEM:
-Max Flow: 72.8 GPM
-Max Pressure: 1000 PSI
FLUID CAPACITIES:
-Fuel Tank: 11 Gal
-Hydraulic Tank: 40 Gal
-Antifreeze: 3 Gal
NOT INCLUDED:
-Pictured Drill Head is NOT included.
-Pictured Drill Pipe is NOT included.
-Machine ONLY!
NOT INCLUDED - Seller has the following items available at an additional cost:
-2024 Ditch Witch JT20 Directional Drill.
-2012 JCB JS220LC Excavator.
