USED 2017 FANUC ROBOCUT A-C400IB

Request a Quote
Add to Cart
X-Axis Travel: 15.7"
Y-Axis Travel: 11.8"
Z-Axis Travel: 10.2"
U/V Axis Travel: 2.36" x 2.36"
Control: Fanuc Series 31i-WB
Degree Taper Cutting: 12° @ 10.0"
Glass Scale Feedback: X and Y Axis Only
Inside Tank Dimensions: 28.7” x 24.8”
Wire Diameter: 0.004" To 0.012"
Tank Capacity: 145 Gal
Internal Work Tank Size: 28.7” x 24.8” x 9.8
Maximum Submerged Cutting Depth: 9.8"
Maximum Work Piece Weight: 1,102 Lbs.
Power Requirement: 200-220 V/3 Phase/60 Hz
Machine Weight: 4,000lbs
Floor Space: 94" x 105"
Auto Wire Threading: Programmable “Z” Axis
Programmable Flushing: Chiller
100% Built in Japan: S232C Input/Output Port for File Transferring
2 USB Ports: Servo Motor Controlled Automatic Water Level Control in Work Tank
3D Coordinate System Rotation: Stainless Submersible Vertical Wire Alignment Gauge
Anti-Crash Protection: Auto Wire Recovery Function
Automatic Corner Rounding: Automatic Power Recovery
Automatic Restart: Ethernet Port
Exclusive Twin Servo Motor Wire Tension System: FANUC Automatic Wire Feed System
Fanuc Filtration Unit: FANUC High Speed Digital / AC Power Supply
FANUC Serial/Digital AC Servo Motors: Fanuc Series 31i-WB 15" Color LCD – Touch Screen
Heidenhain Linear Glass Scales: Independent Column Mounted U and V Axis Slides
NC Command Resolution Of 0.0000004” (0.0001 Mm): Part Program Storage Capacity 4 Megabyte
