USED 2008 KIA KV-45
Overview
Used Kia KV-45. This pre-owned Vertical Machining Center is in great working condition and can be securely delivered to your facility floor. If you have any technical questions about this Kia Vertical Machining Center we can review machine specifications. To request a quote, inquire about rigging and trucking or to schedule an inspection, contact us today.
Specs
Table Size: 45.2” x 18.1”
Table Load Capacity: 1764 lbs
Distance from Spindle Nose to Table: 5.9” – 26.4”
X-Axis Travel: 31.5"
Y-Axis Travel: 19.7"
Z-Axis Travel: 20.4"
Rapid Traverse Rates (X/Y/Z): 787 XY IPM / 591 Z IPM
Magazine Capacity: 20 ATC
Chip to chip: 6 sec.
Tool to Tool: 2sec
Spindle Nose: #40
Spindle Speed: 6,000 RPM
Main Motor: 15/10 HP
Max Tool Length: 11.8”
Max Tool Weight: 22 lbs.
Floor Space: 112" x 118"
Weight: 13,288 lbs
Equipped With
Table Size 45.2” x 18.1”
Table Load Capacity 1764 lbs
Distance from Spindle Nose to Table 5.9” – 26.4”
X-Axis Travel 31.5"
Y-Axis Travel 19.7"
Z-Axis Travel 20.4"
Rapid Traverse Rates (X/Y/Z) 787 XY IPM / 591 Z IPM
Magazine Capacity 20 ATC
Chip to chip 6 sec.
Tool to Tool 2sec
Spindle Nose #40
Spindle Speed 6,000 RPM
Main Motor 15/10 HP
Max Tool Length 11.8”
Max Tool Weight 22 lbs.
Floor Space 112" x 118"
Weight 13,288 lbs
