USED SHANKLIN T-7

With the Shanklin T7 heat shrink tunnel, you are in control. The conveyor speed,
temperature and velocity can easily be adjusted on its straightforward control panel.

FEATURES:
• Polymer mesh conveyor belt
• Painted mild steel construction
• Internal circulation fan and manually operated air flow dampener
• Single heating chamber
• 1/2 horsepower variable speed DC drive by Baldor

Tunnel Passage Dimensions
Length: 42″ / 1067 mm
Width: 22” / 558 mm
Height: 12″ / 304.8 mm

Machine Dimensions
Length: 74″ / 1880 mm
Width: 34 1/2″ / 876 mm
Height: 82″ / 2083 mm (max.)

Conveyor Height
Minimum: 28″ / 711 mm
Maximum: 40″ / 1016 mm

Aperture
Width: 20” (508 mm)
Height: 7” (178 mm)

Tunnel Length
32” (813 mm)

Electrical Requirements
440V, 3pH, 60Hz
