NEW PMC PM-250VS

- Outside Diameter (threaded): 20–250 mm
- Thread Pitch Range: 4–25 mm pitch
- Max. In-Feed Thread Length: 350 mm
- Max. Thru-Feed Thread Length: Free for extension
- Rolling Dies Max. Outside Diameter: 320 mm
- Rolling Dies Bore Diameter: 120 mm (standard) or 100 mm (option)
- Rolling Dies Max. Width: 350 mm
- Variable Spindle Speeds: 0–60 RPM
- Die-Spindle Diameter (2 pcs roller spindle): 120 mm (S) or 100 mm (O)
- Max. Inclination of All-2-Spindles: From 0° up to 10° (for thru-feed)
- Distance Between Die-Spindle Centers: 300–560 mm
- Height from Table Surface to Spindle Center: 420 mm
- Max. Rolling Pressure: 160 ton
- Die-Spindle Main Drive Motor: 75 HP
- Variable Speed Drive: 100 HP inverter
- Hydraulic Motor: 30 HP
- Coolant System: 1 HP
- Machine Net Weight (approx.): 15000 kg
- Machine Gross Weight (approx.): 15500 kg
- Machine Dimensions (L×W×H): 390 × 240 × 238 cm
- Shipping Dimensions (L×W×H): 430 × 240 × 238 cm

* All models available with Automation Linkage (magazine loader + auto feed + unloader).
* Design and technical data are subject to continuously improve and modify without notice.
