USED SEPRO FALCON (ICON GOLD RECOVERY) SB350 (I350)

Sepro Falcon SB350 Concentrator
Make: Sepro Falcon (iCON Gold Recovery)
Model: SB350 (i350)
Type: Centrifugal Concentrator
Condition: Unused Surplus - Still on Manufacture's Skid
General Model Specifications:
Solids Capacity: 15 TPH (Max)
Slurry Capacity: 30m³/hour, 132 U.S. GPM (Max)
Slurry Density: 5% - 65% Solids
Capacity of Concentrate per Batch: 3-6 Kgs
Max Particle Size: 2.5 mm
Concentrating Surface Area: 0.23 m²
G Force Range: 100-150 G's (37-45 Hz)
Electric Motor Power: 5HP (3.7 kW)
Electrical Specifications:
Voltage: 220 Volt
Frequency: 50/60 Hz
Process Water Consumption: 3-5 m³/hr. (13-22 US GPM)
Process Water Pressure: 30-45 PSI
Rinse Time: 60-90 Seconds
Solids Capacity: 15 TPH (Max)
Slurry Capacity: 30m³/hour, 132 U.S. GPM (Max)
Slurry Density: 5% - 65% Solids
Capacity of Concentrate per Batch: 3-6 Kgs
Max Particle Size: 2.5 mm
Concentrating Surface Area: 0.23 m²
G Force Range: 100-150 G's (37-45 Hz)
Electric Motor Power: 5HP (3.7 kW)
Electrical Specifications:
Voltage: 220 Volt
Frequency: 50/60 Hz
Voltage: 220 Volt
Frequency: 50/60 Hz
Process Water Consumption: 3-5 m³/hr. (13-22 US GPM)
Process Water Pressure: 30-45 PSI
Rinse Time: 60-90 Seconds
Overall Dimensions:
Length: 0.98m
Width: 0.98m
Height: 1.43m
Weight: 446 Kgs
Length: 0.98m
Width: 0.98m
Height: 1.43m
Weight: 446 Kgs
Location: Western USA
