NEW EMERSON HT1F15AS

THE SOLAHD HT1F15AS, MANUFACTURED BY EMERSON, IS A 15 KVA, THREE-PHASE ENCAPSULATED NON-VENTILATED AUTOMATION TRANSFORMER DESIGNED FOR HARSH INDUSTRIAL ENVIRONMENTS AND HAZARDOUS LOCATIONS COMPLYING WITH CLASS I, DIVISION 2, GROUPS A, B, C, AND D. IT FEATURES A PRIMARY VOLTAGE RATING OF 480 VAC DELTA AND A SECONDARY VOLTAGE RATING OF 208Y/120 VAC, OPERATING AT A FREQUENCY OF 50/60 HZ. BUILT WITH A RUGGED ROLLED STEEL NEMA TYPE 3R ENCLOSURE, THIS WALL-MOUNTED UNIT PROTECTS AGAINST DUST AND MOISTURE WHILE OFFERING SUPERIOR SHOCK AND VIBRATION RESISTANCE. IT UTILIZES A UL CLASS 200 DEGREES CELSIUS INSULATION SYSTEM WITH A 115 DEGREES CELSIUS TEMPERATURE RISE UNDER FULL LOAD. ELECTROSTATICALLY SHIELDED TO ENSURE QUALITY POWER, THE TRANSFORMER IS ENCAPSULATED WITH ELECTRICAL-GRADE SILICA AND EPOXY AND FEATURES COPPER LEAD WIRE TERMINATIONS. THE UNIT HAS PHYSICAL DIMENSIONS OF 20 INCHES IN WIDTH, 11 INCHES IN DEPTH, AND 17 INCHES IN HEIGHT, WITH A WEIGHT OF APPROXIMATELY 315 LBS.
