USED 1986 ROSBACK 220 Perf and Score

1986 Rossback 220 Perf and Score
ALI# 106439

The Rosback 220 is a high-speed perforator/scorer/slitter designed for continuous, accurate production runs of hundreds to thousands of sheets.
Core Performance Features
Speed: Up to 24,000 feet/hour
Accuracy: 100% registration with sheet deflectors and micrometer dial for angular adjustments
Feeding: Positive, continuous vacuum feeding (eliminates marking on sensitive stock)
Controls: Separate vacuum and pressure controls for enhanced performance
Ergonomics: Ergonomically located operating controls
Durability: Heavy-duty construction, years of trouble-free operation
Standard Equipment
2 sets of slot perforating heads with burr rollers
1 set of scoring/creasing heads
8 perforating blades
Drive rollers
Full circle shaft supports (223 only)
Tool kit and spare parts kit
Head Capacity
Up to 5 heads
Material Handling
Weight range: 9-lb. onionskin to 1/16" board
Sheet size: Min. 5" x 4.6" (12.7 x 11.7 cm), Max. 20" x 23" (52 x 58 cm)
Perf line spacing: Min. 3/4" standard; narrow margin (3/8" from edge) available
Edge margin: Standard 3/4"
