USED STUDER S 30

Centres distance: 650 mm25,59 in
Centres height: 175 mm6,89 in
Cross (X): 255 mm10,04 in
Max grinding diameter: 250 mm9,84 in
Cross speed: 0,012-6 mm/min0,0005-0,2362 ipm
Cross: 0,001-0,05 mm/min0,0000-0,0020 ipm
External spindle power: 5,5 Kw
External spindle speed: 2110 Rpm
Internal spindle speed: 50000 Rpm
Wheel band thickness: 63 mm2,48 in
Max wheel diameter: 400 mm15,75 in
Spindle power: 0,55 Kw
Rotating speed: 30-1000 Rpm
Taper: morse 5
Taper: MORSE 3
Quill diameter: 50 mm1,97 in
Open steadies: si
Closed steadies: si
Available in stock: si
