NEW JTEKT TRD-SR2500V-7474-CN

The Jtekt TRD-SR2500V-7474-CN is an incremental rotary encoder designed for rotational position and speed sensing. It provides a resolution of 2500 Pulses Per Revolution (PPR), generating quadrature A, B, and Z-phase output signals. The encoder utilizes a line driver output circuit, optimized for reliable signal transmission over distance. It operates with a typical supply voltage range of 4.75 to 5.25 VDC and supports a maximum response frequency of 100 kHz. This model features a solid shaft design and is equipped with an integrated cable terminated by a connector for electrical interface.
