Features Include
All Components Readily Available From Your Local Suppliers
Precision Guillotine Drive Providing the Best Shearing System Available
Infinitely Variable, POWER, Quick-Change Blade Gap Adjustment
36” travel PLC backgauge with Go-To and multi-job programmability.
Manual swingaway backgauge
| Max Thickness | 0.5" | 12.7 mm |
| Length of Blade | 10' | 3 m |
| Hyd/Mech | Hyd | Hyd |
| Back Gauge | 36" | 914.4 mm |
| Power | 40 hp | 29.8 kW |
| SPM | 10 strokes/min. | 10 strokes/min. |
| Weight | 30000 (LBS) | 30000 (LBS) |
Extremely heavy duty, 36” travel backgauge with new faster and more precision ballscrews and Cybelec control
POWER Automatic quick-change blade gap adjustment
(2) hand slots and (2) t-slots in table
Ball transfers in table
4’ squaring arm with scale
5 year parts/2 year PLC / 5 year limited onsite labor warranty
T-slot across front edge of shear table
Manifold centralized lube system
