USED MITSUBISHI Q64DA

The Mitsubishi Q64DA is a 4-channel Digital-to-Analog (D/A) converter module designed for use with the MELSEC-Q Series programmable controller platform. It accepts 16-bit signed binary digital input values and outputs precision analog voltage (±10V DC) or current (0–20mA DC) signals across four independent channels. The module communicates via the Mitsubishi MELSEC-Q backplane bus, mounts directly onto a MELSEC-Q series base unit, and requires an external 24V DC power supply for analog output operation.
Specification
Value
Brand
Mitsubishi Electric
Model / Part Number
Q64DA
Series / Platform
MELSEC-Q
Module Type
D/A Converter Module (Digital-to-Analog)
Number of Analog Output Channels
4 channels (CH1–CH4)
Digital Input Resolution
16-bit signed binary
Normal Resolution Range
–4096 to +4095
High Resolution Mode Range
–12288 to 12287 / –16384 to 16383
Analog Voltage Output Range
–10 to +10V DC
Voltage Output Load Resistance
1 kΩ to 1 MΩ
Analog Current Output Range
0 to 20 mA DC
Current Output Load Resistance
0 to 600 Ω
Absolute Max Voltage Output
±12V DC
Absolute Max Current Output
21 mA DC
D/A Conversion Speed
800 µs/channel
I/O Points Occupied
16 points
Internal Current Consumption (5V DC)
0.34 A
External Power Supply Voltage
22.85 to 28.8V DC (24V DC nominal)
Output Short-Circuit Protection
Yes
Channel Isolation
Not isolated between output channels
Height
98 mm
Width
27.4 mm
Depth
90 mm
Weight
0.19 kg
Compatible Programming Software
GX Developer, GX Works2
Status Indicator
RUN LED (On=Normal, Flashing=Offset/Gain mode, Off=Error/WDT)
Product Status
Discontinued by Manufacturer
