USED REED A23
Overview
Specs
Maximum Thread Diameter: 3.750 inches
Minimum Thread Diameter: .250 inches
Min. - Max. Thread Diameter (Thru-feed): 1/4" - 1"
Min. - Max. Threading Diameter (In-feed): 1/4" - 3-3/4"
Max Dia. Dies: 4 inches
Maximum Rolling Force: 15 pounds
Max Die Width: 2.375 inches
Maximum Thread Length (In-feed): 2-3/8"
Maximum Thread Length (Thru-feed): 11"
Spindle Diameter: 1.777 inches
Spindle Speeds: 117-617 rpm
Cam Speeds: 6 - 29
Main Motor: 10 hp
Weight approx: 4700 pounds
Floor Space approx: 76"L x 40"W
