USED PHENOSPEX B.V. PLANTEYE F500

The Phenospex PlantEye F500 is a multispectral 3D laser scanner designed for automated, non-destructive plant phenotyping in laboratories, greenhouses, growth chambers, and field environments. The system combines high-resolution 3D laser scanning with multispectral imaging (RGB + NIR) to simultaneously capture plant morphology and physiological characteristics in a single scan. It generates detailed 3D point clouds and calculates plant traits such as height, biomass, leaf area, NDVI, and chlorophyll-related indices without moving or damaging the plant. The PlantEye F500 has since been superseded by the PlantEye F600, but it remains widely used in research laboratories and breeding programs.

---------------------------------------------------------------

Key Highlights
- High-resolution 3D laser scanning with multispectral imaging
- Non-destructive plant phenotyping
- Combines 3D morphology with RGB and NIR spectral data
- Measures 10+ morphological and spectral plant parameters
- Calculates NDVI, NPCI, PSRI, greenness, and biomass
- Operates indoors and outdoors, including direct sunlight
- Generates open-format 3D point cloud (PLY) files
- Compatible with HortControl analysis software
- Easily integrates with gantries, conveyors, robots, and field platforms
- Designed for automated, high-throughput plant research
---------------------------------------------------------------

Applications / Uses

- Plant phenotyping
- Crop breeding research
- Plant physiology studies
- Greenhouse automation
- Field phenotyping
- Disease detection
- Drought and stress monitoring
- Precision agriculture
- Agricultural biotechnology
- Academic and crop science research
---------------------------------------------------------------

Typical Specifications (Summary)

- Technology: 3D Laser Scanning + Multispectral Imaging
- Spectral Sensitivity: 380–900 nm
- Spectral Bands: 4 (RGB + NIR)
- Laser: 940 nm Class 1M
- Measurement Rate: 35 XZ profiles/second
- Morphological Parameters: 10+
- Connectivity: Wi-Fi, Ethernet
- Operating Temperature: −10°C to +50°C
- Humidity: 0–100% RH
- Power Supply: 24 VDC (10–36 VDC)
- Power Consumption: 50 W
- Protection Rating: IP65
- Dimensions: 440 × 210 × 99 mm
- Weight: 8.3 kg
