NEW NMB U3B1-20K-B

The NMB (Minebea) U3B1-20K-B is a high-accuracy, compact tension and compression load cell from the U3B1-B Series. It features an all-stainless steel construction, making it well-suited for use in corrosive or demanding environments such as hopper, tank, and general industrial weighing systems. With a rated capacity of 20 kgf (196.1 N) and a rated output of 3 mV/V, this load cell delivers precise and repeatable force measurement performance.
Specification
Value
Brand
NMB (Minebea)
Model / Part Number
U3B1-20K-B
Series
U3B1-B
Product Type
Load Cell (Tension / Compression)
Rated Capacity
20 kgf (196.1 N)
Rated Output
3 mV/V ± 0.015 mV/V
Non-Linearity
0.05 %R.O.
Hysteresis
0.05 %R.O.
Repeatability
0.03 %R.O.
Safe Overload
150% R.C.
Ultimate Overload
200% R.C.
Recommended Excitation Voltage
10 V or less
Material
Stainless Steel
Load Direction
Tension and Compression
Capacity Range (Series)
196.1 N (20 kgf) ~ 9.807 kN (1 tf)
Rod End
Optional
Approval / Certification
NTEP Approved (Series)
Typical Application
Hopper, tank, and general industrial weighing systems; corrosive environments
We warranty all items for 30 days from date of purchase.
