USED 1993 FADAL 6030

Table Size 62.5" x 30"
Floor to Table Surface 36"
T-Slots (No. x Width x Span) 5 x .687" x 5.5"
Cutting Feed Rate (X/Y/Z) .01-250 ipm / 375 @ 150%
Rapid Travel Rate (X/Y/Z) 400(X/Y/Z) ipm
Max. Weight on Table 4,120 lbs.
Axis Drive Motor (X/Y/Z) 5,000 lbs. thrust
Ball Screw Size 44mm dia. (X/Y) 38mm (Z)
Longitudinal (X Axis) Travel 60"
Latitudinal (Y Axis) Travel 30"
Vertical (Z Axis) Travel 30"
Spindle Nose to Table 5.5" - 35.5"
Spindle Center to Column Ways 30"
Main Motor - Spindle Horse Power 22.5 HP / 30 HP (option)
Spindle Torque 220 ft-lbs.
Accuracy, Axis Positioning ± .0003"
Accuracy, Axis Repeatability ± .00015"
Spindle Speed 10,000 rpm
Spindle Orientation Electromechanical
Spindle Taper No. 40
ATC, Number of Tools 21
ATC, Tool Selection Random / Bi-directional
Max. Tool Diameter 3"
(Without Adjacent Tools)
(6")
Max. Tool Length 15"
Max. Tool Weight 15 lbs.
Machine Width x Depth 158" x 103"
Machine Max. Height 122"
Machine Weight 17,000 lbs.
