USED MILLROCK TECHNOLOGY, INC. STELLAR LABORATORY FREEZE DRYER

The Millrock Technology STELLAR® Laboratory Freeze Dryer is a versatile laboratory-scale tray lyophilizer designed for research, process development, diagnostic kit production, and small-scale manufacturing. It incorporates many of the advanced features found in larger production freeze dryers, including the Opti-Dry® Gen2 PC/PLC control system, automated recipe management, predictive maintenance, and remote connectivity. The STELLAR system supports applications ranging from proof-of-concept studies to pilot production while maintaining excellent process control and scalability.

The system offers 3.75 to 6.25 ft² (0.348–0.581 m²) of shelf area with 3 to 5 shelves, an internal exposed-coil condenser capable of condensing 12 L of ice in 24 hours, and condenser temperature options of -53°C or -85°C. Available options include pneumatic or hydraulic stoppering, capacitance manometer, manifold, LN₂ cooling, cleanroom configuration, and 21 CFR Part 11-compliant software.

---------------------------------------------------------------
Key Highlights

- Laboratory-scale tray freeze dryer (lyophilizer)
- Opti-Dry® Gen2 PC/PLC control system
- 3–5 heated shelves
- Shelf area from 3.75 to 6.25 ft²
- Internal exposed-coil condenser
- Condenser temperatures of -53°C or -85°C
- Ice condenser capacity: 12 L
- Ice condensing rate: 12 L/24 hours
- Automatic and manual operating modes
- Ethernet connectivity and remote diagnostics
- Optional pneumatic or hydraulic stoppering
- 21 CFR Part 11 software available
- Suitable for laboratory, R&D, and small-scale production applications
---------------------------------------------------------------

Applications / Uses

- Pharmaceutical formulation development
- Biopharmaceutical research
- Vaccine development
- Diagnostic kit manufacturing
- Protein and enzyme preservation
- Cell and tissue preservation
- Biological sample lyophilization
- Academic research
- Process development
- Small-scale GMP production
---------------------------------------------------------------

Typical Specifications (Summary)

- Type: Laboratory Tray Freeze Dryer
- Shelf Area: 3.75–6.25 ft² (0.348–0.581 m²)
- Number of Shelves: 3–5
- Shelf Size: 10 × 18 in (254 × 457 mm)
- Shelf Temperature Range: -45°C to +65°C (-53°C condenser) or -70°C to +65°C (-85°C condenser)
- Shelf Construction: Hollow fluid-filled, 316L stainless steel
- Condenser Temperature: -53°C or -85°C
- Condenser Capacity: 12 L
- Ice Condensing Rate: 12 L/24 hours
- Vacuum Control: Pirani gauge with optional capacitance manometer
- Vacuum Pump: Corrosion-resistant
- Control System: Opti-Dry® Gen2 PC/PLC
- Connectivity: Ethernet with remote access capability
- Refrigeration: Air-cooled, water-cooled, or optional NitroLyo® (LN₂)
- Electrical: Typically 230 VAC, 50/60 Hz (configuration dependent)
