USED LIZZINI SIRIO SYSTEM 10

Capacity: 300x1000 mm [WORKING CAPACITY]
Centres distance: 1000 mm
Centres height: 150 mm
Max grinding lenght: 1000 mm
Max grinding diameter: 300 mm
Max internal diameter: 150 mm
[TABLE]
Stroke: 1070 mm
Cross speed: 0,1 - 6 mm/min
Tilt: 9 °
[FEEDS]
Cross: 0,0025 - 0,025 mm/min
[WHEELHEAD]
External spindle power: 5,5 Kw
Notes: orientabile 90°
[LEFT WHEEL]
Wheel band thickness: 70 mm
Max wheel diameter: 450 mm
Hole diameter: 127 mm
[WORKPIECE HEAD]
Rotating speed: 650 Rpm
Tilt: 90 °
[EXTRA]
Total power supply: 15 HP
Machine total weight: 4800 Kg
Floor space: 4160x1600 mm
Tooling included: vasca filtro a carta, apparecchio per interni, flange, mole
Filtration unit: vasca filtro a carta
Maintenance & Use books: Yes
Electrical drawings: Yes
Availability: pronta
Available in stock: si
Relevant updates made on the machine: ricondizionamento generale, verniciatura completa a spruzzo
