USED FPT DINO

Capacity: 2800x2200x800 mm [WORKING CAPACITY]
Longitudinal (X): 2800 mm
Vertical (Z): 800 mm
Cross (Y): 2200 mm
Distance between columns: 1672 mm
[CNC]
CNC: Heidenhain 430
[HEAD 1]
Type: TULCE
Spindle taper: HSK63A
A axis: 360.000x0,001 °
C axis: 360.000x0,001 °
Max speed: 18000 Rpm
Max power: 20 Kw
Coolant: CTS 20Bar
[FEEDS]
Rapid X: 35 m/min
Rapid Y: 35 m/min
Rapid Z: 35 m/min
[TABLE]
Floorspace (LxWxH): 3000x1200 mm
Capacity: 8000 Kg
[ATC]
Positions: 40
[HEAD 2]
Max speed: 10000 Rpm
Max power: 44 Kw
[EXTRA]
Total power supply: 63,2 HP
Machine total weight: 41300 Kg
High Pressure: 20Bar
CE Certification: Yes
