Orbital X Anderson & Vreeland CL50 Whirl A Way Polymer Removal System

Orbital X Anderson & Vreeland CL50 Whirl A Way Polymer Removal System

ALI# 106395

Orbital X is a multi‑function, stack‑style plate processor designed for water‑wash plates. It combines washout, exposure, and drying in one unit, with optional detack or post‑expose sections.The Whirl-A-Way CL50 removes polymer residue and extends the lifeof washout solutions. This low-maitenance system uses centrifugal force to separate suspended polymer solids from water flexo washout solutions. The solids are collected in a disposable plastic bag while the clean washout solution is recirculated back into the system for reuse and improved efficiency. The Whirl-A-Way CL-50 is a simple to use system with components easily accessed from the front.

Orbital X

The Anderson & Vreeland Orbital X is a multi‑function, stack‑style plate processor designed for water‑wash plates. It combines washout, exposure, and drying in one unit, with optional detack or post‑expose sections.

Key Features

Temperature‑controlled washout tank (8.5 gallons) with stainless steel wetted parts to prevent corrosion

Magnetic and PVC plate mount with easily adjustable brush mount

Digital timers for accurate washout and exposure control

Vacuum pump for plate handling

Electronic solid‑state ballasts for exposure lamps

Thermostat‑controlled three‑drawer dryer with forced hot air (2250W heaters)

Optional detack or post‑expose light drawer with solid‑state ballasts and safety shut‑off

Optional high or medium output exposure (16 lamps)

Compact, stackable design ideal for crowded workspaces

CL50

Dimensions 24" wide x 27" deep x 48" high

Electrical 20 volts / 1-phase / 60 hertz / 12 amps

Weight 360 lbs
