USED HYUNDAI LATHE
Overview
SKT250L Horizontal Lathe (Used) 2011 , Very clean and well maintained, Great machine! Controller Fanuc 0i-TC Swing 29.5″ Maximum Cutting Diameter 19.7″ Maximum Turning Length 52″ Travel X Axis 11.4″ Travel Z Axis 53.1″ Ways Boxed Spindle A2 – 8 Max Bar Work Diameter 3″ Max RPM 3,600 rpm Rapid Traverse X Axis 787 ipm Rapid Traverse Z Axis 945 ipm Turret 12 Tools Tool Size (Square Shank) 1″ sq Tool Size (Round Shank) 2″ Index Time – Tool to Next Tool .3 sec Chuck ( Samwoo Kitagawa ) 12″ Horsepower 30 HP Geared Head 2 Gear Ranges Torque 556.9 Ft-lbs Work light Yes Weight 16,534 lbs Bed 45 deg Coolant System 43 psi Automatic Tool Setter Yes Tailstock Quill diameter 3.9″ Tailstock Quill Travel – Manual 4.7″ Tailstock Body Travel 53.1″ Tailstock Quill Internal Taper MT# 5 Optional Equipment Chip Conveyor Right Hinge Programmable SLU 3.2 Steady Rest 2″ to 7.87″ Manual Base Shot pine engages into turret and manual clamp Auto Lube 3 month Warranty Parts & Labor
Specs
CNC controller: Fanuc 0i-TC
Swing: 29.5″
Maximum Cutting Diameter: 19.7″
Maximum Turning Length: 52″
Travel X axis: 11.4″
Travel Z axis: 53.1″
Guide Ways Boxed on X Linear For Z: Boxed
Spindle Nose: A2 8
Max Bar Work Diameter: 3″
Spindle Speed: 3,600 rpm
Rapid Traverse X axis: 787 ipm
Rapid Traverse Z axis: 945 ipm
Turret: 12 Tools
Live Tool Max. Speed: –
Live Tool Power: 7.5 HP
Tool Size (Square Shank): 1″ sq
Tool Size (Round shank): 2″
Index Time (1 station/1 full rev): .3 sec
Chuck: ( Samwoo Kitagawa ) 12″Main 12″
Tail Stock Quill Diameter: 3.9″
Tail Stock Quill Travel: Manual 4.7″
Tail Stock Body Travel: 53.1″
Tail Stock Quill Internal Taper: MT# 5
Gear Box: 2 Gear Ranges
Horsepower(30min./Peak): 30 HP
Torque: 556.9 Ft-lbs
Weight: 16,534 lbs
Bed: 45 deg
