NEW HEXAGON XI

Leitz Reference Xi
The High-Flexibility Ultra-High Accuracy Coordinate Measuring Machine
The Leitz Reference Xi series of ultra-high accuracy coordinate measuring machines (CMMs) from Hexagon Manufacturing Intelligence are optimised for flexibility.
These ultra-high accuracy machines are available with optional sophisticated temperature compensation features including the XT option extended temperature range of 15 °C to 35 °C, complete with protective bellow covers, and the PULSE environmental monitoring system, offering the ability to operate the machine outside a temperature-controlled environment.
Leitz Reference Xi CMMs offer unparalleled flexibility with a wide range of probe head options from the HP-S-X1 coupled with the HH-A-T2.5 or HH-A-T5 continuous wrist, to the HP-S-X3C fixed measurement head, up to the HP-S-X5-HD designed for use with extra-long stylus extensions or heavy styli clusters.
The accuracy is there in every situation – whether measuring with indexing or fixed probe heads. With a multi-sensor controller, the Leitz Reference Xi series is also well equipped for the integration of optical sensors.
Features & Benefits
Ceramic Ram

Selected sizes of the Leitz Reference Xi are equipped with a ceramic Z-ram to maximise robustness and stiffness. It is the ideal construction to achieve the optimal measuring performance required by a wide range of modern applications.
Future Ready

The Future Ready concept optimises the CMM for the SENMATION intelligent sensor automation system upgrade. The universal pre-cabling enables a simple integration process at any time, allowing for flexible application changes without costly downtime.
TRICISION™

A moving bridge with triangular profile provides optimum stiff-to-mass ratio for unquestioned precision and long-term stability.
Status Messaging Lights

The Status Message Light kit integrates LED alert lights into the CMM so you can check machine status at a glance, even at a distance. This means the CMM can be left to measure, allowing you to optimise time and resource management.
High Resolution Steel Scales

High-quality steel scales and automatic temperature compensation reduce the effect of temperature fluctuations on the measurement process.
Rotary Tables

As an integrated or on-top version, rotary tables up to a diameter of 600 mm and a maximum table load of 550 kg can be used for 4-axis scanning and component positioning.
Temperature Sensor

An optional exchangeable temperature sensor for the LSP-S2 Scan+ and the HP-S-X5 HD enables automatic part-temperature measurement at the workpiece (integrated in the measurement program).
XT Option

The XT option enables accurate and reliable measurement in the expanded temperature range of 15 °C to 35 °C on selected Leitz Reference Xi machine models, which is indispensable in environments where temperature conditions are not controlled.
