NEW OCEAN 600
Overview
FEATURES & BENEFITS
3-Axis Computer Controlled with 4 or 5-Axis Configurations Available
New HP-1 Generator Provides Higher Speeds and Lower Wear
100 Liter Water Dielectric Tank (std.)
1 Touch Release Button for Quick Change of Drill Chuck
Power Backslide (W-Axis)
Pendant Box for Easy Manual Operation
High Speed 64 Amp Generator
E-Learning Software
Specs
Table travel (X,Y axes): 600 x 400 mm
Work table size: 600 x 400 mm
Z axis travel: 400 mm
W axis travel: 450 mm
Max. workpiece height: 400 mm
Max. workpiece weight: 800 kgs
Power input: According to local voltage
Max. average current: 25 Amps( 32 / 64 Amps Optional )
Power capacity: 3.8 KVA
Electrode diameter: 0.1 ~ 3.0mm
Machine net weight: 1100 kgs
Depth / Width / Height: 1030 x 1630 x 1960 mm
*Due to continuous research and development, all specifications and design characteristics are subject to change without prior notice.: *Due to continuous research and development, all specifications and design characteristics are subject to change without prior notice.
