NEW OCEAN 45
Overview
FEATURES & BENEFITS
Touch Screen HMI Control for Easy Operation
New HP-1 Generator Provides Higher Speeds and Lower Wear
1 Touch Release Button for Quick Change of Drill Chuck
Power Backslide (W-Axis)
Automatic Electrode WearCompensation
10 Sets of Workpiece Coordinates
32 Amp Generator
The sparking drilling is use of digital control mechanism, which can effectively enhance the small size drilling and speed by stability.
With HP1+(plus) high-speed circuit to enhance drilling speed.
Specs
Table travel (X,Y axes): 450 x 350 mm
Work table size: 600 x 376 mm
Z axis travel: 350 mm
W axis travel: 200 mm
Max. workpiece height: 360 mm
Max. workpiece weight: 600 kgs
Power input: According to local voltage
Max. average current: 32 Amps (64A optional)
Power capacity: 3.8 KVA
Electrode diameter: 0.1 ~ 3.0mm (3.0 ~ 6.3mm Opt.)
Machine net weight: 1300 kgs
Depth / Width / Height: 1520 x 1620 x 2230 mm
*Due to continuous research and development, all specifications and design characteristics are subject to change without prior notice.: *Due to continuous research and development, all specifications and design characteristics are subject to change without prior notice.
