NEW HYUNDAI WIA L300C
Overview
Hyundai Wia L300C
Features
Sturdiness secured through the adoption of an all Axis box guide
Highly accurate direct link and highly sturdy all-in-one structure
Highly accurate pretension double-anchor method
Minimized heat deformation in the main spindle
Gearless type main spindle models are all equipped with a mill turret.
Big Bore Spindle (L300C Series)
Specifications
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalogue.
Specs
Max Turning Dia: 560 mm
Max Turning Length: 720 mm
Chuck Size: 12″ inch
Driving Method: GEAR
Spindle RPM: 3,000 r/min
Spindle Output: 26/22 kW
Spindle Torque: 1098.7/929.7 N.m
Travel(X/Z): 355/750 mm
Rapid Travel(X/Z): 20/24 m/min
Slide Type: BOX
No. of Tools: 12 EA
Tool Size: 25/50 mm
