NEW HYUNDAI WIA L300LMC
Overview
Hyundai Wia L300LMC
Features
Sturdiness secured through the adoption of an all Axis box guide
Highly accurate direct link and highly sturdy all-in-one structure
Highly accurate pretension double-anchor method
Minimized heat deformation in the main spindle
Gearless type main spindle models are all equipped with a mill turret.
Integrated process realized through adoption of 8″ sub spindle : models equipped with sub spindle
Big Bore Spindle (L300C Series)
Specs
Max Turning Dia: 500 500
Max Turning Length: 1,260 600
Chuck Size: 12″ 12″
Driving Method: Belt Belt
Spindle RPM: 3,000 3,000
Spindle Output: 22/18.5 22/18.5
Spindle Torque: 786.9/661.7 786.9/661.7
Travel(X/Z): 355/1,350 355/750
Rapid Travel(X/Z): 20/24 20/24
Slide Type: BOX BOX
No. of Tools: 12 12
Tool Size: 25/50 25/50
Milling Tool Speed: 4,000 4,000
