NEW YAMA SEIKI MVP-4032

Model: MVP-4032
X-axis travel: 4,000 mm ( 157.48″ )
Y-axis travel: 3,200 mm ( 125.98″ )
Z-axis travel: 1,000 mm ( 39.37″ ) ( Opt. 1,200 mm ( 47.24″ ) 、 1,400 mm ( 55.11″ ) )
W-axis travel: 1,250 mm ( 49.21″ )
Distance between columns: 2,680 mm ( 105.51″ )
Distance nose to table: 200 ~ 2,450 mm ( 7.87″ ~ 96.45″ )
Table size ( X x Y ): 4,020 x 2,400 mm
( 158.26″ x 94.48″ )
T slot ( Width x Dist. ): 28 x 200 mm ( 1.10″ x 7.87″ )
Table load capacity: 15,000 kg ( 33,000 lb )
Spindle taper: CAT50
Spindle power ( cont. / 30 min. ): 22 / 26 kW ( 30 / 35 HP )
Spindle speed: V : 10 ~ 4,000 rpm   ;   H : 20 ~ 2,000 rpm
Spindle motor torque: 827 / 977 N-m
Spindle clamping force: 1,800 kg ( 3,968 lb )
X-axis rapid feed rate: 15 m/min. ( 590 IPM )
Y-axis rapid feed rate: 12 m/min. ( 472 IPM )
Z-axis rapid feed rate: 10 m/min. ( 394 IPM )
W-axis rapid feed rate: 3 m/min. ( 118 IPM )
Cutting feed rate: 1 ~ 5,000 mm/min. ( 1 ~ 315 IPM )
Tool magazine capacity: 48 Station ( 60 Opt. )
Max. tool diameter / adj. pocket empty: 125 / 250 mm ( 4.92″ / 9.84″ )
Max. tool length ( from gauge line ): 400 mm ( 15.7″ )
Max. tool weight: 25 kg ( 55 lb )
Coolant tank capacity: 750 L ( 198 gallon )
Lubrication oil tank capacity: 6 L ( 1.6 gallon )
Hydraulic unit tank capacity: 290 L ( 76 gallon )
Hydraulic power: 7.4 kW ( 10 HP )
Pneumatic pressure requirement: 5 kg / cm² ( 17.12 PSI )
Power Requirement: AC 220 + 10% 3 phase / 80 KVA
CNC control: FANUC Oi-MD
Machine weight: 50,000 kg
( 110,231 lb )
Dimensions
( L x W x H ): 11,000x 8,540x 6,260 mm
( 453″ x 336″ x 246″ )
