NEW KIWA KMH-300

The KMH-300 Series offer an integrated full rotary B-Axis and a reliable FANUC Oi-MF control with a 15 in. LCD screen. The machine features excellent chip evacuation and easy access for set-up / maintenance. A spindle oil cooling system and coolant-through ball-screws are standard.
The KMH-300 has a compact footprint of 140 in. depth x 107 in. width including the chip conveyor.
FEATURES & BENEFITS
Dual 320mm Pallets
Roller Guide Ways
15HP/15,000rpm Direct Drive
Big Plus Spindle 30 Taper
15” Fanuc LCD Screen
Coolant Through Ballscrews (CTB)
Integrated Full Rotary B-Axis
Excellent Chip Evacuation
Easy Access for Setup & Maintenance
OPTIONS
AI Nano Contour Control II with 200 Block Look Ahead
20,000 RPM Spindle
6 Pallet APC
Upgraded Chip Conveyor – LNS-Turbo MH500
40, 90 or 120 Tools
Automatic Tool Length Measurement and Breakage Detection
High Pressure Coolant through Spindle (20 Bar , 500 PSI
X, Y, and Z Scales
31iMB Control
