NEW HYUNDAI WIA LF2600/2SP
Overview
Hyundai Wia LF2600/2SP
Features
Rigid servo turret
Symmetrical headstock to prevent thermal distortion
Pretensioned double-anchored ballscrew for superior positioning and repeatability accuracy
High-speed gantry loader for cycle time reduction
Split bed prevents vibration transfer
Specifications (metric)
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
Specifications
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
Specs
Max Turning Dia: 14″ inch
Max Turning Length: 6.7″ inch
Chuck Size: 10″ inch
Driving Method: Belt
Spindle RPM: 3,000 r/min
Spindle Output (Max/Cont.): 30/25 hp
Spindle Torque: 363.6 (Max) ft.lb
Travel(X/Z): 7.5″ / 6.7 inch
Rapid Travel(X/Z): 945 / 945 in/min
Slide Type: BOX
No. of Tools: 2 x 10 EA
Tool Size (ID/OD): 1″ / 1.5″ inch
