NEW HYUNDAI WIA L300LC
Overview
Hyundai Wia L300LC
Features
Sturdiness secured through the adoption of an all Axis box guide
Highly accurate direct link and highly sturdy all-in-one structure
Highly accurate pretension double-anchor method
Minimized heat deformation in the main spindle
Gearless type main spindle models are all equipped with a mill turret.
Big Bore Spindle (L300C Series)
Specifications (metric)
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
Specifications
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
Specs
Max Turning Dia: 22″ inch
Max Turning Length: 52″ inch
Chuck Size: 12″ inch
Driving Method: GEAR
Spindle RPM: 3,000 r/min
Spindle Output (max/cont.): 35/30 hp
Spindle Torque (max/cont.): 810/686 ft.lbs
Travel(X/Z): 14″ / 53″ inch
Rapid Travel(X/Z): 787/945 in/min
Slide Type: BOX
No. of Tools: 12 EA
Tool Size (ID/OD): 1″ / 2″ inch
