NEW HYUNDAI WIA L300LA
Overview
Features
Sturdiness secured through the adoption of an all Axis box guide
Highly accurate direct link and highly sturdy all-in-one structure
Highly accurate pretension double-anchor method
Minimized heat deformation in the main spindle
Gearless type main spindle models are all equipped with a mill turret.
Integrated process realized through adoption of 8″ sub spindle : models equipped with sub spindle
Specifications (metric)
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
Specifications
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
Specs
Max Turning Dia: 19.7″ inch
Max Turning Length: 52″ inch
Chuck Size: 10″ inch
Driving Method: GEAR
Spindle RPM: 3,600 r/min
Spindle Output (max/cont.): 30/25 hp
Spindle Torque (max/cont.): 556.86/468.72 ft.lb
Travel(X/Z): 11.4″/53″ inch
Rapid Travel(X/Z): 787/945 in/min
Slide Type: BOX
No. of Tools: 12 EA
Tool Size (ID/OD): 1″ / 2″ inch
