NEW HYUNDAI WIA HI-MOLD560
Overview
Mold Machining
High Speed Machining Center for Mold Machining with highly precise spindle and optimal mold package
Features
Highly reliable bridge type machining center
Highly accurate main spindles with ultra-precise angular contact bearings
Built-in ultra-high-speed (40,000rpm) main spindle for the highest quality surface finish (Opt.)
Built-in 5-axis table to satisfy various processing needs (Hi-MOLD560/5A)
Hyundai WIA mold package delivers optimal processing of mold parts
Latest SIEMENS 828D control equipped with exceptional processing software
Specifications
Specifications are subject to change without notice for quality improvement.
In case of any further information, please refer to the machine catalog.
Specs
Table Size: 49.2″×23.6″ inch
Max. Load Capacity: 1,760 lb
Spindle Driving Method: Built in
Spindle Taper: HSK-A63
Spindle RPM: 24,000 r/min
Spindle Power: 44/33 HP
Spindle Torque: 70.8/53.4 lbf.ft
Travel(X/Y/Z): 39.3″/22″/17.7″ inch
Rapid Feed Rate(X/Y/Z): 50/50/50 m/min
Slide Type: LM
No. of Tools: 24 EA
Tool Change Time
(Chip To Chip): 5.5 sec
CNC: S840D
